| No. | Parameter | Value |
|---|---|---|
| S.No | Product Parameter | SMD P1.8mm |
| 1 | Pixel Pitch in mm | P1.8 |
| 2 | Pixel Density in sqm | 284,444 |
| 3 | Module Size in mm | 320 x 160 |
| 4 | Cabinet Size in mm | 640 x 480 |
| 5 | Cabinet Weight in KG | 6.5 |
| 6 | Viewing Angle in H/V | 160/140 |
| 7 | Brightness in cd/sqm | 850 |
| 8 | Color Depth | 14 bit |
| 9 | Refresh Rate in Hz | ≥3840 |
| 10 | Voltage | 220v |
| 11 | Avg. Power Consumption (W) | 225 |
| 12 | Max Power Consumption (W) | 650 |
| 13 | Service Excess | Front |
| 14 | IP Grade Front/Rear | 31/31 |
| 15 | Operating Temperature (-/+) | 0℃~+50℃ |
| 16 | Operating Humidity | 0-50% |
| 17 | Life Time in hrs | 1,00,000 |
| 18 | MTBF in hrs | 5,000 |
| No. | Component | Value |
|---|---|---|
| S.No | Component Parameter | SMD P1.8mm |
| 1 | LED Chip | Nation star Copper |
| 2 | PCB | 4 Layer |
| 3 | Driver IC | ICN/DP/MBI |
| 4 | Power Supply | Chuangliang |
| 5 | Controller | Nova |
| 6 | Cabinet Material | Die Cast |
