| No. | Parameter | Value |
|---|---|---|
| S.No | Product Parameter | SMD P10mm |
| 1 | Pixel Pitch in mm | P10 |
| 2 | Pixel Density in sqm | 10,000 |
| 3 | Module Size in mm | 320 x 160 |
| 4 | Cabinet Size in mm | 960 x 960 |
| 5 | Cabinet Weight in KG | 27 |
| 6 | Viewing Angle in H/V | 140/140 |
| 7 | Brightness in cd/sqm | 5,500 |
| 8 | Color Depth | 14 bit |
| 9 | Refresh Rate in Hz | ≥3840 |
| 10 | Voltage | 220v |
| 11 | Avg. Power Consumption (W) | 350 |
| 12 | Max Power Consumption (W) | 750 |
| 13 | Service Excess | Rear |
| 14 | IP Grade Front/Rear | 65/54 |
| 15 | Operating Temperature (-/+) | –10℃~+65℃ |
| 16 | Operating Humidity | 0-99% |
| 17 | Life Time in hrs | 50,000 |
| 18 | MTBF in hrs | 5,000 |
| No. | Component | Value |
|---|---|---|
| S.No | Component Parameter | SMD P10mm |
| 1 | LED Chip | Atenti SMD |
| 2 | PCB | 2 layer |
| 3 | Driver IC | ICN/SM/DP |
| 4 | Power Supply | Rong |
| 5 | Controller | Nova |
| 6 | Cabinet Material | Die Cast |
