| No. | Parameter | Value |
|---|---|---|
| S. No. | Product Parameter | SMD P4mm |
| 1. | Pixel Pitch (mm) | 4 |
| 2. | LED Type | SMD |
| 3. | LED Configuration per pixel | 1R + 1PG + 1PB |
| 4. | Resolution Density (pixel/m2) | 62,500 pixel/m² |
| 5. | Brightness per/m2 | 5,000 NITS |
| 6. | Module Size/Dimension/Pixel (W x H) | 320 X 160 |
| 7. | Driver IC | ICN/SM/MBI or Equivalent |
| 8. | Power Supply | Rong |
| 9. | Min View Distancing | 4m |
| 10. | Viewing Angle | H:160°, V:160° @ 50% brightness |
| 11. | Cabinet Size | Customizable |
| 12. | Brightness Adjustment | Manual, 256 level; Auto, 8 levels |
| 13. | Color Processing | 16 bit/color |
| 14. | Available Color Palett | 281 trillion colors |
| 15. | Operating Temperature | -10°C ~+65°C |
| 16. | Lifetime | >100,000 Hours @50% of initial brightness |
| 17. | Input Volyage | AC110V/220V/380V ±10% |
| 18. | Input Power Frequency | >50/60Hz |
| 19. | Screen Power Consumption | Max: 700w/m², Average: 350w/m² |
| 20. | Refresh Rate | ≥3840Hz |
| 21. | Defect Rate | ≤0.0001 |
| 22. | Data Transfer Method | RJ45 |
| 23. | Operating Humidity | 10%~95%RH |
| 24. | Weatherproof Grade | IP65 |
| 25. | Control Method | Synchronized with computer monitor |
| 26. | Way Of Drive | Constant current driving, 1/5 |
| 27. | MTBF | > 10,000 hours |
| 28. | Control Distance | CAT5: 120 m (no repeating); Optical fiber transmission: 500m |
| 29. | Serviceability | Rear Access |
| 30. | Certificates | CE, ROHS, ISO, BIS |
